Icon Item List
Version: 1.0.2
Author: modern algebra
Date: 16 June 2013
Version History
- <Version 1.0.2> 2013.06.16 - Added an optional background colours feature
- <Version 1.0.1> 2013.06.14 - Added more font options
- <Version 1.0.0> 2013.06.08 - Original Release
Description
This script changes the item window so that it shows only icons to represent the item and a number to show how many are held.
It is also compatible with my
Customizable Item Menu, if the reduced space for item descriptions are problematic.
Features
- Shows items only as icons, instead of by their names.
- Easily customizable to change how the number is shown, as well as the size of each slot. You can also change the way the name shows up in the description window.
Screenshots
Instructions
Paste the script into its own slot in the Script Editor, above Main but below Materials.
The script is otherwise plug & play, but you can customize some of its features. See the instructions in the header and the Editable Region to see how.
Script
#==============================================================================
# Icon Item List
# Version: 1.0.2
# Author: modern algebra (rmrk.net)
# Date: 16 June 2013
#++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
# Description:
#
# This script changes the item window so that it shows only icons to
# represent the item and a number to show how many are held.
#++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
# Instructions:
#
# Paste this script into its own slot in the Script Editor, above Main but
# below Materials.
#
# You can also customize the size of each icon space, as well as various
# aspects of the font to draw the number, including size, colour, and whether
# it is bolded. As well, you can set it so that the name of the item shows up
# in the help window, and you can set its format as well. To do so, go to the
# Editable Region at line 53 and read the instructions contained there.
#
# The script also allows you to set it so that each icon has a background
# colour and a shadow. Those are set at lines 90-95. You can also set it so
# that each item has its own background colour by using either of the
# following codes in its notebox
#
# \back_colour[x]
# \back_colour[r, g, b, a]
#
# If the former, the xth colour on the windowskin palette will be used. If
# the latter, then it will choose a colour with those rgb and alpha values.
#
# Note: using the Name feature will reduce the amount of space you have for
# the actual description of your items. By default, it takes a whole line
# (although you can change that by altering the NAME_FORMAT string). If that
# is a problem, you could turn the feature off (but then it would not show
# the name anywhere). Another solution would be to increase the size of the
# help window. That can be done by using my Customizable Item Menu script,
# which you can find here:
#
# http://rmrk.net/index.php/topic,46516.0.html
#
# If you use the Image in Description feature, you should probably remove the
# \\icon from the NAME_FORMAT at line 112.
#==============================================================================
$imported = {} unless $imported
$imported[:MA_IconItemList] = true
module MA_IconItemList
#\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\
# BEGIN Editable Region
#||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
# Size Settings
RECT_WIDTH = 28 # The width of each slot for the icon
RECT_HEIGHT = 28 # The height of each slot for the icon
SPACING = 12 # The space between icon slots
# Number Settings
# NUM_FONTNAME - The font for the numbers. It should be an array of strings,
# with each string being a font name ranked by priority. It will use the
# first font in the array that exists on the user's computer. It will use
# the default if set to nil.
NUM_FONTNAME = nil
NUM_FONTSIZE = 20 # The size of the font showing how many items possessed
NUM_BOLD = true # Whether the number of items should be bolded
NUM_ITALIC = false # Whether the number of items should be italicized
NUM_SHADOW = true # Whether the number of items should have a shadow
NUM_OUTLINE = true # Whether the number of items should have an outline
NUM_ALIGN = 2 # Alignment of number. 0 => Left; 1 => Centre; 2 => Right
DO_NOT_DRAW_NUM_IF_1 = false # Don't draw num if only possess 1 of item
# Colours
# Each of the colour settings can be either an integer, an array, or a
# Color object. If an integer (0, 1, ..., 31), it will take its colour from
# that index of the windowskin's colour palette. If an array, then it must
# be in the form: [red, green, blue, alpha], where each is an integer between
# 0 and 255. alphas is optional. Color objects may also be used, in which
# case it is: Color.new(red, green, blue, alpha)
#
# Examples:
# NUM_COLOUR = 0
# NUM_COLOUR_WHEN_MAX = [100, 200, 145]
# NUM_OUT_COLOUR = Color.new(75, 75, 75, 160)
#
# If you set NUM_OUT_COLOUR to nil, then it will just use the default
# outline colour.
NUM_COLOUR = 0 # The colour of the number
NUM_COLOUR_WHEN_MAX = 17 # The colour of the number if holding maximum
NUM_OUT_COLOUR = nil # The colour of the outline, if showing. If nil, default
# Back Settings
# These allow you to set a background colour for your items. The same
# The same options for setting colours are available here as they are above.
# Additionally, if set to nil, there will not be any colour.
#
# If you do decide to use them, recommended values for each are:
# BACK_DEFAULT_COLOUR = Color.new(64, 64, 64, 160)
# BACK_SHADOW_COLOUR = Color.new(0, 0, 0, 128)
BACK_DEFAULT_COLOUR = nil # Default Main Colour
BACK_SHADOW_COLOUR = nil # Colour of Shadow
# Name Settings
# SHOW_NAME_IN_DESCRIPTION - Set to true if you want to show the name of the
# item in the description window. Set it to false otherwise.
SHOW_NAME_IN_DESCRIPTION = true
# NAME_FORMAT - This is the format of the name, if shown in the description
# window. The code \\icon will be replaced with the icon of the currently
# selected item, and \\name will be replaced with the name of the currently
# selected item. All the other message codes are also recognized, but you
# need to use two backslashes (\\), not one (\). Examples:
# Good: \\c[16]
# Bad: \c[16]
# The code \n (one backslash) will make a new line.
NAME_FORMAT = "\\icon \\c[16]\\name\\c[0]\n"
#||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
# END Editable Region
#//////////////////////////////////////////////////////////////////////////////
end
#==============================================================================
# *** RPG::BaseItem
#++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
# Summary of Changes:
# new method - back_colour
#==============================================================================
class RPG::BaseItem
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Back Colour
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def maiil_back_colour
unless @maiil_back_colour
if note[/\\BACK_COLOU?R\[(.+?)\]/i]
dig = $1.scan(/\d+/).collect { |x| x.to_i }
@maiil_back_colour = dig.empty? ? nil : dig.size == 1 ? dig[0] : dig
else
@maiil_back_colour = MA_IconItemList::BACK_DEFAULT_COLOUR
end
end
return @maiil_back_colour
end
end
#==============================================================================
# *** Window_MAIIL_Help
#++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
# This window can mix in to a help window to show the names of items.
#==============================================================================
module Window_MAIIL_Help
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Set Item
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def set_item(item, *args)
if item # if Item passed
text = MA_IconItemList::NAME_FORMAT.dup # Get Name Format
text.gsub!(/\\ICON/i, "\\i[#{item.icon_index}]") # Replace Icon
text.gsub!(/\\NAME/i, item.name) # Replace Name
text += item.description # Add Description
if $imported[:"MA Customizable Item Menu 1.0.x"] && self.is_a?(Window_MACIM_Help) # if using Custom Item Menu
image = item.is_a?(MACIM_RPG_ItemWeaponArmor) ? item.macim_desc_image : ""
set_text(text, image) # Set Text (CIM)
else
set_text(text) # Set Text (NO CIM)
end
else # if nil Passed
set_text("") # Set Text when no item
end
end
end
#==============================================================================
# ** Window_ItemList
#++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
# Summary of Changes:
# overwritten methods - create_contents; text_color; draw_item;
# draw_item_number; col_max; spacing; line_height
# aliased method - help_window=
# new method - maiil_draw_item_icon
#==============================================================================
class Window_ItemList
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Create Contents
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def create_contents(*args)
super(*args)
maiil_reset_font
end
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Setup Font
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def maiil_reset_font
fn = MA_IconItemList::NUM_FONTNAME ? MA_IconItemList::NUM_FONTNAME : Font.default_name
contents.font = Font.new(fn, MA_IconItemList::NUM_FONTSIZE) # name and size
contents.font.bold = MA_IconItemList::NUM_BOLD # Set Bold
contents.font.italic = MA_IconItemList::NUM_ITALIC # Set Italic
contents.font.shadow = MA_IconItemList::NUM_SHADOW # Set Shadow
contents.font.outline = MA_IconItemList::NUM_OUTLINE # Set outline
oc = MA_IconItemList::NUM_OUT_COLOUR ? MA_IconItemList::NUM_OUT_COLOUR : Font.default_out_color
contents.font.out_color = text_color(oc) # outline color
end
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Text Colour
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def text_color(n)
case n
when Integer then super(n)
when Array then Color.new(*n)
when Color then n
else super(0)
end
end
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Draw Item
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def draw_item(index)
item = @data[index] # get item
if item # if Item passed
rect = item_rect(index) # get rect
contents.clear_rect(rect)
maiil_draw_item_icon(rect, item) # draw icon
draw_item_number(rect, item) # draw number of items held
end
end
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Draw Item Icon
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def maiil_draw_item_icon(rect, item)
x, y = rect.x + 2, rect.y + ((rect.height - 24) / 2) # Get coordinates
if item.maiil_back_colour # Draw Border
bcs = MA_IconItemList::BACK_SHADOW_COLOUR
contents.fill_rect(x, y, 26, 26, text_color(bcs)) if bcs
contents.fill_rect(x - 1, y - 1, 26, 26, text_color(item.maiil_back_colour))
end
draw_icon(item.icon_index, x, y, enable?(item)) # Draw Icon
end
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Draw Item Number
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def draw_item_number(rect, item)
num = $game_party.item_number(item) # Get Number
return if MA_IconItemList::DO_NOT_DRAW_NUM_IF_1 && num < 2
# Set Number Colour
if num == $game_party.max_item_number(item)
contents.font.color = text_color(MA_IconItemList::NUM_COLOUR_WHEN_MAX)
else
contents.font.color = text_color(MA_IconItemList::NUM_COLOUR)
end
contents.font.color.alpha = translucent_alpha unless enable?(item) # Set Alpha
# Adjust Rect
rect2 = rect.dup
rect2.y += (rect.height - contents.font.size)
rect2.height = contents.font.size
# Draw Number
draw_text(rect2, num, MA_IconItemList::NUM_ALIGN)
end
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Column Max
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def col_max; (contents_width / (MA_IconItemList::RECT_WIDTH + spacing)); end
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Spacing
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def spacing; MA_IconItemList::SPACING; end
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Line Height
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def line_height; MA_IconItemList::RECT_HEIGHT; end
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Help Window=
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
if MA_IconItemList::SHOW_NAME_IN_DESCRIPTION # IF showing name in Description
# If #help_window= has been redefined in Window_ItemList
if instance_methods(false).include?(:"help_window=")
alias maiil_helpwinset_4ka5 help_window=
def help_window=(*args)
maiil_helpwinset_4ka5(*args) # Call Original Method
@help_window.extend(Window_MAIIL_Help)
end
else # Inheriting #help_window= from Window_Selectable
def help_window=(*args)
super(*args) # Call Original Method
@help_window.extend(Window_MAIIL_Help)
end
end
end
end
#==============================================================================
# *** Scene_ItemBase
#++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
# Summary of Changes:
# overwritten method - cursor_left?
#==============================================================================
class Scene_ItemBase
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
# * Determine if Cursor Is in Left Column
#~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
def cursor_left?
true
end
end
If it is not copying correctly, you can also get the script from
Pastebin.
Credit
Support
Please post in this topic at RMRK.net if you have any questions, suggestions, error reports, or comments about this script. It is perfectly fine to post here even if this topic has not been posted in for a very long time.
Please do not message me privately, as any concerns you have are likely shared by others and they will benefit from our correspondence being public. Additionally, I am occasionally absent, and posting publically will allow other members to assist you when I am unable to do so quickly.
Known Compatibility Issues
If you are using Yanfly's Ace Item Menu, this script should be placed below it.
Author's Notes
I haven't produced anything for a very long time, so I figured this was something I could do in an hour. It's pretty messy code, but I don't have a lot of time these days.
Terms of Use
I adopt RMRK's default
Terms of Use.
